DCBORE Well Graphics
Wells and ground water measuring points acc. to DIN 4943:2005
Only in combination with DCBORE
Description
New DIN 4943:2005 available including cover sheet and data sheets B1, B2 and B3 !
Well and gauge pipes:
- Scaled graphics of different pipe diameters
- Any number of pipes / multi-level pipes
- Haunches possible, display of base caps
- Different tube types:
Top tube, solid tube, bottom tube, lifting tube - Different types of filter tubes
- Display of water level and pump symbol
- Different pipe heads above/below surface, cap etc.
Pipe and well head:
- Different head types:
Concrete base, concrete ring, steel tube, street cap or hydrant cap - Well pit with different measures and inclinations
- Alternatively cover, vent pipe, hatching
Fillings:
- Any types of fillings with symbol editor
- Graphical display with symbols and colors
- Several fillings (counter fillings) possible
- Scaled in depth and diameter
- With haunch, sealing pipe or through possible
- Infill baskets and infill pipes
Labelling etc.:
- Free labelling in any depths
- Lines to tube, filling, center or freely selected
- Automatic labelling for tubes and fillings
- Alternative labelling left or right
- Labels above and below well / gauge
- Vertical labelling along the well
- Different types of spacers, perforations, cementation items, packers
Only in combination with DCBORE
